Page #116 background imageLoading...
Page #116 background image
Item # Description Part # Quantity
276 Condensate Trap Retainer 250-874, 250-875 P-344 1
280 Condensate Trap 180-013 P-115 1
285 Return Temperature Sensor 240-134 P-363 1
290 Heat Exchanger 170-034 P-322 1
295 Supply Duplex Temperature Sensor 240-133 P-362 1
300 Refractory 250-762 P-317 1
305 High Limit Switch 240-030 1
315 Burner 180-187 P-313 1
320 Burner Gasket 255-069 P-378 1
325 Heat Exchanger Lid Gasket 255-029 P-374 1
330 Sight Glass Housing 250-057 P-107A 1
331 Sight Glass 250-059 1
332 Sight Glass Gasket 255-025 1
333 Sight Glass to Lid Gasket 255-023 1
335 Ignitor Gasket 250-050
P-317
1
336 Ignitor
240-141
1
337 Ignitor / Fan Coupler Screws 150-260 10
112
Section: Appendices
