IBERITAL DE RECAMBIOS, S.A.
2.4.- FEED UNIT GROUP.
44) Gasket
46) Spray head
47) Water drainage system
49) Solenoid valve
The feed unit consists of a hot press brass block in which the infusion chamber has been set.
Pressing the coffee feed button turns on the pump (29) and activates the solenoid valve (49).
2.5.- BOILER
50) Feed unit
52) Injector
53) Heat exchanger
This boiler is made of copper and is intersected by a heat exchanger (53) which is connected to the
feed unit (50).
During the feed cycle cold water is sent into the exchanger through the use of a pump
and injector (52). Between the heat exchanger (53) and the feed unit (50) a thermo siphon circulation is
established, through the difference in temperature and the density of water
which maintains the unit and the correct temperature needed for making the coffee.
A thermostat (61) controls the temperature of the heating element inside the boiler, in order not to pass
over the correct rate. In this case the machine turns off. To be turned on press the resent button located
on the thermostat.
GROUPS HEATING
ELEMENT
2
3800 W / 5000 W
3
5000 W / 5000 W
