IBIX 25 - Page 13

12
POS. DESCRIPTION
4 PRESSURE REGULATOR
4A AIR ADJUSTMENT CONTROL
4B PRESSURE GAUGE
4C AIR FILTER
4D CONDENSATE DRAINING VALVE
9 COMPRESSED AIR QUICK CONNECTION
10 ANTICONDENSATE FILTER
11 CONDENSATE DRAINING VALVE
12 KIT H2O (OPTIONAL)
13 PRESSURE RELIEF VALVE
14 BLASTING MATERIAL FILLING FUNNEL
14A QUICK EXHOUST VALVE
