7.3.3 Replacing the twin hose
The twin hose connects the gun to a valve in the lower part of the eco-blaster. Two other hoses go from this
valve to the main air valve, located below the protective guard. The figure shows that the 4 hoses in question
are in 4 different colors (red and black for the twin hose, white and blue for the main air valve hoses). If one
or more of these hoses have to be replaced, the same arrangement and the same color-coding should be
maintained (red to blue, white to black).
To disconnect the hose without damaging the 2 parts, it is necessary to press the valve
where the hose enters, then carefully pull the hose.
