IBIX 25 - Unscheduled Maintenance

40
7.3.4 Gun maintenance
Good maintenance of the gun and all its parts is essentially important to guarantee efficient gun operation.
Disassemble the gun by screwing out its screws [P]. Screw out the nozzle locking the nut [R] and estract the
nozzle [Q]. Screw out the nozzle-holder [T] from the gun and check the condition of the inert hose [U] and of
the valve [V]. Replace the pneumatic valve if necessary.
If you have an HELIX gun, check the helix [Z].
P
P
P
P
P
P
R
R
R
Q
Q
Q
T
T
T
U
U
U
V
Z
