Appendix A. Specification tables
Memory module placement
This memory module placement table shows you how to place dual inline Memory
modules (DIMMs) into the sockets labelled DIMM1 Bank 0 and DIMM Bank 1. Refer
to the section “Identifying system board parts (machine type 2193)” on page 9-2 for
the location of the DIMM sockets. Use 168-pin SDRAM PC-133 3.3v DIMMs.
Table 1: Memory module placement
DIMM Bank 0 DIMM Bank 1 TOTAL Memory
16M NONE 16M
32M NONE 32M
64M NONE 64M
128M NONE 128M
16M 16M 32M
32M 16M 48M
64M 16M 80M
128M 16M 144M
16M 32M 48M
32M 32M 64M
64M 32M 96M
