Specification tables
A-9
Connector functions
The following table includes the specific functions of the connectors. Refer to the
section “Locating system board jumpers and connectors (machine type 2193)” on
page 9-4 for an illustration of the connector locations.
Table 7: Connector functions
Connector Function
BAT1 Battery socket
J1 ATX Power connector
J2 CPU FAN
J4 Hard Disk connector (Primary IDE)
J5 CD-ROM Drive connector (Secondary IDE)
J6 Video Bridge (DFP) connector
J7 USB and LAN connector
J9 DIMM Connector 1
J10 DIMM Connector 2
J11 PCI Slot 1
J12 PCI Slot 2
J13 PCI Slot 3
