REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
6550-23N/23S/33N/63N/63S/73N
(d)
7-8
R565 1-215-481-00 METAL 330K 1% 1/4W
R566 1-215-859-00 METAL OXIDE 22 5% 1W F
R567 1-216-077-91 RES,CHIP 15K 5% 1/10W
R568 1-249-437-11 CARBON 47K 5% 1/4W
R569 1-216-643-11 METAL CHIP 470 0.50%1/10W
R570 1-249-417-11 CARBON 1K 5% 1/4W
R571 1-215-926-00 METAL OXIDE 33K 5% 3W F
R572 1-249-437-11 CARBON 47K 5% 1/4W
R573 1-247-887-00 CARBON 220K 5% 1/4W
R574 1-249-421-11 CARBON 2.2K 5% 1/4W
R575 1-260-314-11 CARBON 68 5% 1/2W
R576 1-249-437-11 CARBON 47K 5% 1/4W
R577 1-215-908-00 METAL OXIDE 33 5% 3W F
R578 1-216-448-11 METAL OXIDE 39 5% 2W F
R579 1-247-883-00 CARBON 150K 5% 1/4W
R580 1-216-077-91 RES,CHIP 15K 5% 1/10W
R581 1-249-429-11 CARBON 10K 5% 1/4W
R582 1-249-402-11 CARBON 56 5% 1/4W F
R583 1-216-073-00 RES,CHIP 10K 5% 1/10W
R584 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R585 1-249-417-11 CARBON 1K 5% 1/4W
R586 1-249-421-11 CARBON 2.2K 5% 1/4W
R587 1-249-417-11 CARBON 1K 5% 1/4W
R589 1-249-425-11 CARBON 4.7K 5% 1/4W
R590 1-215-453-00 METAL 22K 1% 1/4W
R591 1-214-844-81 METAL 150 1% 1/2W
R592 1-214-844-81 METAL 150 1% 1/2W
R594 1-216-033-00 RES,CHIP 220 5% 1/10W
R595 1-215-477-00 METAL 220K 1% 1/4W
R596 1-215-423-00 METAL 1.2K 1% 1/4W
R597 1-259-880-11 CARBON 2.2M 5% 1/4W
R599 1-249-417-11 CARBON 1K 5% 1/4W
R600 ¡ 1-205-998-11 CEMENTED 1 5% 10W
R602 1-219-513-11 CARBON 4.7M 5% 1/2W
R603 1-249-403-11 CARBON 68 5% 1/4W
R604 ¡ 1-220-827-91 REGISTER 560K 5% 1/2W
R605 1-220-778-81 FUSIBLE 0.1 10% 1/2W
R606 1-218-768-11 METAL CHIP 470K 0.50%1/10W
R607 1-216-081-00 RES,CHIP 22K 5% 1/10W
R608 1-215-473-00 METAL 150K 1% 1/4W
R609 1-216-665-11 METAL CHIP 3.9K 0.50%1/10W
R610 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R611 1-216-009-91 RES,CHIP 22 5% 1/10W
R612 1-247-791-91 CARBON 22 5% 1/4W
R613 1-219-513-11 CARBON 4.7M 5% 1/2W
R614 1-216-345-11 METAL OXIDE 0.47 5% 1W F
R615 1-216-117-00 RES,CHIP 680K 5% 1/10W
R616 1-216-121-91 RES,CHIP 1M 5% 1/10W
R617 1-216-025-91 RES,CHIP 100 5% 1/10W
R618 1-216-635-11 METAL CHIP 220 0.50%1/10W
R619 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
R620 1-216-687-11 METAL CHIP 33K 0.50%1/10W
R621 1-216-098-00 RES,CHIP 110K 5% 1/10W
R622 1-247-791-91 CARBON 22 5% 1/4W
R623 1-216-615-91 METAL CHIP 33 0.50%1/10W
R624 1-216-611-11 METAL CHIP 22 0.50%1/10W
R625 1-260-332-51 CARBON 2.2K 5% 1/2W
R626 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R627 1-249-377-11 CARBON 0.47 5% 1/4W F
R628 1-216-674-11 METAL CHIP 9.1K 0.50%1/10W
R629 1-249-441-11 CARBON 100K 5% 1/4W
R630 ¡ 1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R631 ¡ 1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R633 1-249-429-11 CARBON 10K 5% 1/4W
R634 ¡ 1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R635 1-215-925-11 METAL OXIDE 22K 5% 3W F
R636 1-260-119-11 CARBON 47K 5% 1/2W
R637 1-215-902-11 METAL OXIDE 47K 5% 2W F
R638 ¡ 1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R639 ¡ 1-211-874-71 FUSIBLE MELF 0.12 10% 1/2W
R640 1-249-381-11 CARBON 1 5% 1/4W F
R642 1-216-641-11 METAL CHIP 390 0.50%1/10W
R643 1-215-467-00 METAL 82K 1% 1/4W
R645 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R646 1-216-689-11 RES,CHIP 39K 5% 1/10W
R647 1-216-073-00 RES,CHIP 10K 5% 1/10W
R648 1-216-669-11 METAL CHIP 5.6K 0.50%1/10W
R649 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R650 1-215-471-00 METAL 120K 1% 1/4W
R654 1-216-344-00 METAL OXIDE 0.39 5% 1W F
R655 1-247-807-31 CARBON 100 5% 1/4W
R656 1-215-893-11 METAL OXIDE 1.5K 5% 2W F
R660 1-260-119-11 CARBON 47K 5% 1/2W
R661 1-215-902-11 METAL OXIDE 47K 5% 2W F
R663 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R665 1-216-663-11 METAL CHIP 3.3K 0.50%1/10W
R703 1-249-410-11 CARBON 270 5% 1/4W
R704 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R705 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R706 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R707 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R708 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R709 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R710 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R711 1-216-346-00 METAL OXIDE 0.56 5% 1W F
R712 1-215-860-11 METAL OXIDE 33 5% 1W F
R713 1-216-347-11 METAL OXIDE 0.68 5% 1W F
R716 1-215-860-11 METAL OXIDE 33 5% 1W F
R717 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R718 1-215-863-11 METAL OXIDE 100 5% 1W F
R719 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R724 1-216-422-11 METAL OXIDE 18 5% 1W F
R727 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R728 1-215-863-11 METAL OXIDE 100 5% 1W F
R729 1-216-353-00 METAL OXIDE 2.2 5% 1W F
R730 1-216-421-11 METAL OXIDE 12 5% 1W F
R731 1-216-295-91 SHORT 0
R733 1-216-295-91 SHORT 0
R735 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R737 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R739 1-216-073-00 RES,CHIP 10K 5% 1/10W
R741 1-249-377-11 CARBON 0.47 5% 1/4W F
