IBM 6550-23N User Manual

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
6550-23N/23S/33N/63N/63S/73N
9-978-650-01
English
99GL24029-1
Printed in Japan
 1999.7
– 54 –
(d)
R743 1-249-377-11 CARBON 0.47 5% 1/4W F
R745 1-216-298-00 RES,CHIP 2.2 5% 1/10W
R747 1-216-298-00 RES,CHIP 2.2 5% 1/10W
R753 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R755 1-216-667-11 METAL CHIP 4.7K 0.50%1/10W
R903 1-216-049-91 RES,CHIP 1K 5% 1/10W
R904 1-216-049-91 RES,CHIP 1K 5% 1/10W
R905 1-216-295-91 SHORT 0
R906 1-216-073-00 RES,CHIP 10K 5% 1/10W
R907 1-260-087-81 CARBON 100 5% 1/2W
R908 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R909 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R910 1-249-411-11 CARBON 330 5% 1/4W
R911 1-249-416-11 CARBON 820 5% 1/4W
R912 1-216-049-91 RES,CHIP 1K 5% 1/10W
R913 1-216-025-91 RES,CHIP 100 5% 1/10W
R914 1-216-025-91 RES,CHIP 100 5% 1/10W
R915 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R916 1-216-077-91 RES,CHIP 15K 5% 1/10W
R917 1-216-077-91 RES,CHIP 15K 5% 1/10W
R918 1-216-049-91 RES,CHIP 1K 5% 1/10W
R920 1-216-049-91 RES,CHIP 1K 5% 1/10W
R921 1-216-295-91 SHORT 0
R922 1-216-073-00 RES,CHIP 10K 5% 1/10W
R923 1-216-295-91 SHORT 0
R924 1-216-025-91 RES,CHIP 100 5% 1/10W
R925 1-216-113-00 RES,CHIP 470K 5% 1/10W
R927 1-216-295-91 SHORT 0
R929 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R931 1-216-659-11 METAL CHIP 2.2K 0.50%1/10W
R932 1-216-077-91 RES,CHIP 15K 5% 1/10W
R933 1-249-417-11 CARBON 1K 5% 1/4W
R934 1-249-429-11 CARBON 10K 5% 1/4W
R935 1-216-025-91 RES,CHIP 100 5% 1/10W
R936 1-216-025-91 RES,CHIP 100 5% 1/10W
R937 1-216-025-91 RES,CHIP 100 5% 1/10W
R938 1-216-025-91 RES,CHIP 100 5% 1/10W
R940 1-216-661-11 METAL CHIP 2.7K 0.50%1/10W
R943 1-249-413-11 CARBON 470 5% 1/4W
R944 1-216-043-91 RES,CHIP 560 5% 1/10W
R945 1-216-049-91 RES,CHIP 1K 5% 1/10W
R946 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R947 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R951 1-216-025-91 RES,CHIP 100 5% 1/10W
R957 1-216-017-91 RES,CHIP 47 5% 1/10W
R958 1-216-017-91 RES,CHIP 47 5% 1/10W
<VARIABLE RESISTOR>
[ RV501¡1-241-767-21RES, ADJ, CERMET 100K (HV ADJ)
<RELAY>
RY500 1-515-669-21 RELAY
RY601¡1-755-279-11RELAY
<SWITCH>
S602 ¡ 1-771-757-11 SWITCH, PUSH (1 KEY) (POWER)
S901 1-692-431-21 SWITCH, TACTILE (RESET)
S903 1-692-431-21 SWITCH, TACTILE (BRIGHT -)
S904 1-692-431-21 SWITCH, TACTILE (BRIGHT +)
S905 1-692-431-21 SWITCH, TACTILE (MENU)
S906 1-692-431-21 SWITCH, TACTILE (CONT -)
S908 1-692-431-21 SWITCH, TACTILE (CONT +)
<SPARK GAP>
SG501 1-519-422-11 GAP, SPARK
<TRANSFORMER>
T501 ¡ X-4560-154-1 TRANSFORMER ASSY, FLY BACK
(NX-4404//J1L4)
T503 1-433-979-11 TRANSFORMER, FERRITE (DFT)
T504 1-433-978-11 TRANSFORMER, HORIZONTAL DRIVE
T505 1-431-413-11 TRANSFORMER, FERRITE (HST)
T601 ¡ 1-433-847-14 TRANSFORMER, CONVERTER (SRT)
<THERMISTOR>
TH501 1-807-796-11 THERMISTOR
TH600¡1-803-339-11THERMISTOR, NTC
TH601¡1-803-540-11THERMISTOR
<VARISTOR>
VA601¡1-801-268-51VARISTOR ERZV14D471
VA602¡1-801-268-51VARISTOR ERZV14D471
VA603 1-801-268-51 VARISTOR ERZV14D471
(23N, 23S, 63N, 63S)
<CRYSTAL>
X901 1-767-641-11 VIBRATOR, CRYSTAL
X902 ¡ 1-767-933-11 OSCILLATOR, CERAMIC
6550-23N/23S/33N/63N/63S/73N
9-978-650-01 99GL24029-1
The components identified by [ in this
manual have been carefully factory-
selected for each set in order to satisfy
regulations regarding X-ray radiation.
Should replacement be required, replace
only with the value originally used.
