6550-23N/23S/33N/63N/63S/73N
– 2 –
DIAGNOSIS
Failure Power LED
HV/+B Failure Blink Amber (On 0.5 sec, Off 0.5 sec)
H Stop or V Stop (Included S-Cap) Blink Amber (On 0.5 sec, Off 0.5 sec)
ABL Failure Blink Amber (On 0.5 sec, Off 1.5 sec)
Aging/Self-Test Blink Amber (On 0.5 sec, Off 0.5 sec) .... Blink Green (On 0.5 sec, Off 0.5 sec)
TIMING SPECIFICATION
PRIMARY MODE PRIMARY
MODE AT PRODUCTION
MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 MODE 6 MODE 7 MODE 8 MODE 9 MODE 10
RESOLUTION 640 X 480 640 X 480 640 X 480 800 X 600 800 X 600 1024 X 768 1024 X 768 1280 X 1024 1280 X 1024 1600 X 1200
CLOCK 25.175 MHz 31.500 MHz 36.000 MHz 49.500 MHz 56.250 MHz 78.750 MHz 94.500 MHz 135.000 MHz 157.500 MHz 202.500 MHz
— HORIZONTAL —
H-FREQ 31.469 kHz 37.500 kHz 43.269 kHz 46.875 kHz 53.674 kHz 60.023 kHz 68.677 kHz 79.976 kHz 91.146 kHz 93.750 kHz
usec usec usec usec usec usec usec usec usec usec
H. TOTAL 31.778 26.667 23.111 21.333 18.631 16.660 14.561 12.504 10.971 10.667
H. BLK 6.356 6.349 5.333 5.172 4.409 3.657 3.725 3.022 2.844 2.765
H. FP 0.636 0.508 1.556 0.323 0.569 0.203 0.508 0.119 0.406 0.316
H. SYNC 3.813 2.032 1.556 1.616 1.138 1.219 1.016 1.067 1.016 0.948
H. BP 1.907 3.810 2.222 3.232 2.702 2.235 2.201 1.837 1.422 1.501
H. ACTIV 25.422 20.317 17.778 16.162 14.222 13.003 10.836 9.481 8.127 7.901
— VERTICAL —
V. FREQ(HZ) 59.940 Hz 75.000 Hz 85.008 Hz 75.000 Hz 85.061 Hz 75.029 Hz 84.997 Hz 75.025 Hz 85.024 Hz 75.000 Hz
lines lines lines lines lines lines lines lines lines lines
V. TOTAL 525 500 509 625 631 800 808 1066 1072 1250
V. BLK 45 20 29 25 31 32 40 42 48 50
V. FP 10 1 1 1 1 1 1 1 1 1
V. SYNC 2 3 3 3 3 3 3 3 3 3
V. BP 33 16 25 21 27 28 36 38 44 46
V. ACTIV 480 480 480 600 600 768 768 1024 1024 1200
— SYNC —
INT(G) NO NO NO NO NO NO NO NO NO NO
EXT(H/V)/POLARITY YES -/- YES -/- YES +/+ YES +/+ YES +/+ YES +/+ YES +/+ YES +/+ YES +/+ YES +/+
EXT(CS)/POLARITY NO NO NO NO NO NO NO NO NO NO
INT/NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT NON INT
99.5.18 VER.
Power Saving Function
This monitor meets the power-saving guidelines set by
VESA and
E
NERGY
S
TAR, as well as the more stringent
NUTEK .
If the monitor is connected to a computer or video graphics
board that is VESA DPMS (Display Power Management
Signaling) compliant, the monitor will automatically reduce
power consumption in three stages as shown below.
Notes
When your computer is in a power saving mode, MONITOR IS IN
POWER SAVE MODE appears on the screen if you press any
button on the monitor (page 15). After a few seconds, the monitor
enters the power saving mode again. Once the horizontal and
vertical sync signals are detected, the monitor automatically
resumes its normal operation mode.
1
2
3
4
5
Recovery time
—
Approx. 5 sec.
Approx. 5 sec.
Approx. 15 sec.
—
u indicator
Green
Green and orange
alternate
Green and orange
alternate
Orange
Off
Power
consumption
≤ 130 W
≤ 15 W
≤ 15 W
≤ 3 W
≤ 0.5 W
Screen
active
blank
blank
blank
—
Horizontal
sync signal
present
absent
present
absent
—
Vertical
sync signal
present
present
absent
absent
—
Power consumption
mode
Normal operation
Standby (1st mode)
Suspend (2nd mode)
(sleep)*
Active-off (3rd mode)
(deep sleep)*
Power-off
