REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
6550-23N/23S/33N/63N/63S/73N
(a)(d)
7-3
R046 1-216-097-91 RES,CHIP 100K 5% 1/10W
R047 1-216-073-00 RES,CHIP 10K 5% 1/10W
R048 1-211-885-21 METAL 2.2M 5% 1W
R049 1-216-697-91 METAL CHIP 82K 0.50%1/10W
R051 1-216-049-91 RES,CHIP 1K 5% 1/10W
R052 1-216-073-00 RES,CHIP 10K 5% 1/10W
R053 1-219-621-91 METAL 22M 10% 1/4W
R062 1-216-295-91 SHORT 0
R064 1-202-830-00 SOLID 10K 20% 1/2W
R102 1-216-113-00 RES,CHIP 470K 5% 1/10W
R104 1-216-017-91 RES,CHIP 47 5% 1/10W
R106 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R107 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R108 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R109 1-216-113-00 RES,CHIP 470K 5% 1/10W
R111 1-249-401-11 CARBON 47 5% 1/4W F
R117 1-216-295-91 SHORT 0
R118 1-216-295-91 SHORT 0
R119 1-216-113-00 RES,CHIP 470K 5% 1/10W
R130 1-216-022-00 RES,CHIP 75 5% 1/10W
R133 1-249-413-11 CARBON 470 5% 1/4W
R151 1-202-549-00 SOLID 100 20% 1/2W
R161 1-215-394-00 METAL 75 1% 1/4W
R202 1-216-113-00 RES,CHIP 470K 5% 1/10W
R204 1-216-017-91 RES,CHIP 47 5% 1/10W
R206 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R207 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R208 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R209 1-216-113-00 RES,CHIP 470K 5% 1/10W
R211 1-249-401-11 CARBON 47 5% 1/4W F
R217 1-216-295-91 SHORT 0
R218 1-216-017-91 RES,CHIP 47 5% 1/10W
R219 1-216-113-00 RES,CHIP 470K 5% 1/10W
R230 1-216-011-00 RES,CHIP 27 5% 1/10W
R233 1-249-413-11 CARBON 470 5% 1/4W
R251 1-202-549-00 SOLID 100 20% 1/2W
R261 1-215-394-00 METAL 75 1% 1/4W
R302 1-216-113-00 RES,CHIP 470K 5% 1/10W
R304 1-216-017-91 RES,CHIP 47 5% 1/10W
R306 1-216-673-11 METAL CHIP 8.2K 0.50%1/10W
R307 1-216-651-11 METAL CHIP 1K 0.50%1/10W
R308 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R309 1-216-113-00 RES,CHIP 470K 5% 1/10W
R311 1-249-401-11 CARBON 47 5% 1/4W F
R317 1-216-295-91 SHORT 0
R318 1-216-295-91 SHORT 0
R319 1-216-113-00 RES,CHIP 470K 5% 1/10W
R330 1-216-022-00 RES,CHIP 75 5% 1/10W
R333 1-249-417-11 CARBON 1K 5% 1/4W
R351 1-202-549-00 SOLID 100 20% 1/2W
R361 1-215-394-00 METAL 75 1% 1/4W
<SPARK GAP>
SG001 1-519-422-11 GAP, SPARK
SG002 1-517-499-21 GAP, SPARK
SG101 1-517-499-21 GAP, SPARK
SG201 1-517-499-21 GAP, SPARK
SG301 1-517-499-21 GAP, SPARK
*******************************************************************************
A-1346-856-A D BOARD, COMPLETE
****************************
(23N, 23S, 63N, 63S)
A-1346-864-A D BOARD, COMPLETE (33N, 73N)
****************************
3-710-578-01 COVER, VOLUME, 6 MOLD (RV501)
4-072-322-01 HOLDER, LED (D912)
4-382-854-01 SCREW (M3X8), P, SW (+) (IC401, IC503,
IC602, IC605, IC607, IC608, Q503, Q510,
Q520, Q602, D601, D611, D618)
4-382-854-11 SCREW (M3X10), P, SW (+) (D506, Q507)
4-382-854-21 SCREW (M3X14), P, SW (+) (IC702)
<CAPACITOR>
C401 1-107-914-11 ELECT 1000MF 20% 25V
C402 1-117-667-31 FILM 0.47MF 5% 250V
C403 1-107-911-11 ELECT 220MF 20% 50V
C404 1-107-914-11 ELECT 1000MF 20% 25V
C405 1-104-760-11 CERAMIC CHIP 0.047MF 10% 50V
C406 1-137-368-11 FILM 0.0047MF 5% 50V
C407 1-137-372-11 FILM 0.022MF 5% 50V
C410 1-164-005-11 CERAMIC CHIP 0.47MF 25V
C501 1-126-964-11 ELECT 10MF 20% 50V
C502 1-137-370-11 FILM 0.01MF 5% 50V
C503 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C504 1-102-030-00 CERAMIC 330PF 10% 500V
C505 1-109-879-11 CERAMIC 22PF 5% 2KV
C506 1-126-960-11 ELECT 1MF 20% 50V
C507 1-131-653-11 FILM 0.19MF 5% 400V
C508 1-128-526-11 ELECT 100MF 20% 25V
C509 1-162-117-00 CERAMIC 100PF 10% 500V
C510 1-102-228-00 CERAMIC 470PF 10% 500V
C511 1-117-663-11 FILM 0.22MF 5% 250V
C512 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C513 1-107-906-11 ELECT 10MF 20% 50V
C514 1-115-521-11 FILM 0.82MF 5% 250V
C515 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C516 1-119-862-11 FILM 0.3MF 5% 250V
C517 1-137-370-11 FILM 0.01MF 5% 50V
C518 1-117-954-11 FILM 4300PF 3% 1.8KV
C519 1-117-621-11 FILM 1200PF 3% 1.2KV
C520 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C521 1-107-444-11 CERAMIC 100PF 5% 2KV
C522 1-136-684-51 MYLAR 0.0022MF 10% 100V
C523 1-117-660-21 FILM 0.12MF 5% 250V
C524 1-110-641-51 ELECT 33MF 20% 200V
C525 1-136-060-91 FILM 0.047MF 5% 400V
C526 1-165-137-41 CERAMIC 4700PF 10% 500V
C527 1-117-879-91 CAPACITOR 0.01MF 10% 250V
