REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
6550-23N/23S/33N/63N/63S/73N
(d)
7-5
C903 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C905 1-137-375-11 FILM 0.068MF 5% 50V
C906 1-136-177-00 FILM 1MF 5% 50V
C908 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C909 1-126-926-11 ELECT 1000MF 20% 10V
C910 1-107-713-11 ELECT 4.7MF 20% 50V
C911 1-137-370-11 FILM 0.01MF 5% 50V
C912 1-126-933-11 ELECT 100MF 20% 16V
C913 1-130-495-00 FILM 0.1MF 5% 50V
C914 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C915 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C916 1-107-907-11 ELECT 22MF 20% 50V
C917 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C918 1-126-964-11 ELECT 10MF 20% 50V
C920 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C921 1-126-935-11 ELECT 470MF 20% 16V
C922 1-109-889-11 ELECT 1MF 20% 50V
C923 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C924 1-126-965-11 ELECT 22MF 20% 50V
C925 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C926 1-126-935-11 ELECT 470MF 20% 16V
C927 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C928 1-163-021-91 CERAMIC CHIP 0.01MF 10% 50V
C929 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V
C930 1-137-370-11 FILM 0.01MF 5% 50V
C931 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C934 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C935 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C936 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C937 1-107-823-11 CERAMIC CHIP 0.47MF 10% 16V
C938 1-104-653-11 ELECT 220MF 20% 16V
<CONNECTOR>
CN501*1-580-798-11 CONNECTOR PIN (DY) 6P
CN502*1-564-512-11 PLUG, CONNECTOR 9P
CN512 1-695-915-11 TAB (CONTACT)
CN600¡1-251-644-11INLET,AC 3P (WITH NOISE FILTER)
CN601*1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN602*1-506-371-00 PIN, CONNECTOR 2P
CN604 1-695-915-11 TAB (CONTACT)
CN701*1-564-513-11 PLUG, CONNECTOR 10P
CN901*1-508-879-11 BASE POST
CN902*1-564-513-11 PLUG, CONNECTOR 10P
CN903*1-564-511-11 PLUG, CONNECTOR 8P
<DIODE>
D401 8-719-052-90 DIODE D1NL40-TA2
D402 8-719-928-85 ZENER DIODE HZS4.7NB2
D403 8-719-073-01 DIODE MA111-(K8).S0
D404 8-719-058-24 DIODE RB501V-40TE-17
D501 8-719-110-31 ZENER DIODE RD12ESB2
D502 8-719-981-00 DIODE ERC81-004
D504 8-719-110-49 ZENER DIODE RD18ESB2
D505 8-719-941-74 DIODE ERB91-02
D506 8-719-075-18 DIODE FMQ-G2FS
D507 8-719-109-85 ZENER DIODE RD5.1ESB2
D509 8-719-110-17 ZENER DIODE RD10ESB2
D510 8-719-018-82 DIODE RGP02-20EL-6394
D511 8-719-109-89 ZENER DIODE RD5.6ESB2
D512 8-719-911-19 DIODE 1SS119-25
D513 8-719-052-90 DIODE D1NL40-TA2
D514 8-719-970-83 DIODE HSS82
D515 8-719-018-82 DIODE RGP02-20EL-6394
D516 8-719-052-86 DIODE D2L40-TA
D517 8-759-157-40 IC uPC574J
D518 8-719-110-17 ZENER DIODE RD10ESB2
D519 8-719-911-19 DIODE 1SS119-25
D520 8-719-018-82 DIODE RGP02-20EL-6394
D521 8-719-018-82 DIODE RGP02-20EL-6394
D522 8-719-911-19 DIODE 1SS119-25
D523 8-719-911-19 DIODE 1SS119-25
D524 8-719-051-85 DIODE HSS83TD
D525 8-719-051-85 DIODE HSS83TD
D527 8-719-109-85 ZENER DIODE RD5.1ESB2
D601 ¡ 8-719-510-63 DIODE D4SB60L-F
D602 8-719-911-19 DIODE 1SS119-25
D603 8-719-911-19 DIODE 1SS119-25
D604 8-719-911-19 DIODE 1SS119-25
D605 8-719-110-31 ZENER DIODE RD12ESB2
D606 8-719-053-19 DIODE UF4007G23
D607 8-719-053-19 DIODE UF4007G23
D608 8-719-110-49 ZENER DIODE RD18ESB2
D609 8-719-911-19 DIODE 1SS119-25
D610 8-719-928-85 ZENER DIODE HZS4.7NB2
D611 8-719-067-68 DIODE FMC-26UA
D612 8-719-053-19 DIODE UF4007G23
D613 8-719-076-20 DIODE BT149G-412-OT359
D614 8-719-032-12 DIODE D1NS6
D615 8-719-979-58 DIODE EGP10D
D616 8-719-979-58 DIODE EGP10D
D617 8-719-947-06 DIODE RGP10JPKG23
D618 8-719-058-38 DIODE FMN-G12S
D619 8-719-058-38 DIODE FMN-G12S
D620 8-719-300-76 DIODE RH-1A
D621 8-719-911-19 DIODE 1SS119-25
D622 8-719-058-38 DIODE FMN-G12S
D704 8-719-911-19 DIODE 1SS119-25
D901 8-719-073-01 DIODE MA111-(K8).S0
D902 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D903 8-719-050-84 DIODE RB441Q-40T-77
D904 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D905 8-719-911-19 DIODE 1SS119-25
D906 8-719-073-01 DIODE MA111-(K8).S0
D907 8-719-073-01 DIODE MA111-(K8).S0
D908 8-719-073-01 DIODE MA111-(K8).S0
D909 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D910 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D911 8-719-073-01 DIODE MA111-(K8).S0
D912 8-719-075-53 DIODE SML16751WN
D913 8-719-073-01 DIODE MA111-(K8).S0
