REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
6550-23N/23S/33N/63N/63S/73N
(d)
7-6
D914 8-719-073-01 DIODE MA111-(K8).S0
D915 8-719-073-01 DIODE MA111-(K8).S0
D916 8-719-073-01 DIODE MA111-(K8).S0
D917 8-719-073-01 DIODE MA111-(K8).S0
D918 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D919 8-719-073-01 DIODE MA111-(K8).S0
D920 8-719-058-24 DIODE RB501V-40TE-17
D921 8-719-073-01 DIODE MA111-(K8).S0
D922 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
D923 1-216-295-91 SHORT 0
D924 8-719-073-01 DIODE MA111-(K8).S0
D925 8-719-073-01 DIODE MA111-(K8).S0
D926 8-719-073-01 DIODE MA111-(K8).S0
D927 8-719-073-01 DIODE MA111-(K8).S0
D928 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D929 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D930 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D931 8-719-109-89 ZENER DIODE RD5.6ESB2
D932 8-719-109-89 ZENER DIODE RD5.6ESB2
D933 8-719-109-89 ZENER DIODE RD5.6ESB2
D934 8-719-047-98 ZENER DIODE HZU5.6B2TRF
D935 8-719-109-85 ZENER DIODE RD5.1ESB2
D936 8-719-109-89 ZENER DIODE RD5.6ESB2
D937 8-719-109-89 ZENER DIODE RD5.6ESB2
D938 8-719-047-98 ZENER DIODE HZU5.6B2TRF
<FUSE>
F601 ¡ 1-576-231-11 FUSE (H.B.C.) 4A/250V
1-533-223-11 CLIP, FUSE ; F601
<FERRITE BEAD>
FB502 1-410-396-41 FERRITE 0.45UH
FB504 1-412-911-11 FERRITE
FB506 1-412-911-11 FERRITE
FB904 1-543-961-22 FERRITE
<IC>
IC401 8-759-339-59 IC TDA8177
IC501¡8-759-570-29 IC uPC6757CS
IC502 8-759-803-42 IC LA6500-FA
IC503 8-759-803-42 IC LA6500-FA
IC601¡8-759-594-75 IC TEA1504-N2
IC602 8-759-592-79 IC BA00AST-V5
IC603 8-749-016-36 IC TLP621D4-YLF2
IC604 8-759-586-17 IC TL1431CZT
IC605 8-759-513-72 IC PQ12RF11
IC607 8-759-450-47 IC BA05T
IC608 8-759-231-53 IC TA7805S
IC701 8-759-595-52 IC CXA8070AP
IC702 8-749-015-00 IC STK391-110
IC703 8-759-822-38 IC LA6510
IC901 8-759-640-86 IC CXD9529S-LHX
IC902 8-759-594-40 IC CXA8071CP
IC904 8-759-352-91 IC PST9143NL
IC905 8-759-527-76 IC M24C08-MN6T
<CHIP CONDUCTOR>
JR001 1-216-296-91 SHORT 0
JR003 1-216-295-91 SHORT 0
JR004 1-216-295-91 SHORT 0
JR006 1-216-295-91 SHORT 0
JR007 1-216-295-91 SHORT 0
JR008 1-216-296-91 SHORT 0
JR009 1-216-295-91 SHORT 0
JR010 1-216-296-91 SHORT 0
JR011 1-216-296-91 SHORT 0
JR012 1-216-295-91 SHORT 0
JR013 1-216-295-91 SHORT 0
JR014 1-216-296-91 SHORT 0
JR015 1-216-295-91 SHORT 0
JR016 1-216-295-91 SHORT 0
JR017 1-216-295-91 SHORT 0
JR018 1-216-295-91 SHORT 0
JR019 1-216-296-91 SHORT 0
JR020 1-216-296-91 SHORT 0
JR021 1-216-296-91 SHORT 0
JR022 1-216-295-91 SHORT 0
JR023 1-216-295-91 SHORT 0
JR024 1-216-296-91 SHORT 0
JR025 1-216-296-91 SHORT 0
JR027 1-216-296-91 SHORT 0
JR028 1-216-296-91 SHORT 0
JR029 1-216-295-91 SHORT 0
JR030 1-216-295-91 SHORT 0
JR032 1-216-296-91 SHORT 0
JR033 1-216-296-91 SHORT 0
JR034 1-216-295-91 SHORT 0
JR038 1-216-296-91 SHORT 0
JR604 1-216-295-91 SHORT 0
JR606 1-216-295-91 SHORT 0
<COIL>
L501 1-406-663-21 INDUCTOR 47UH
L502 1-406-663-21 INDUCTOR 47UH
L503 1-411-594-41 INDUCTOR 5mH
L505 1-412-552-11 INDUCTOR 2.2mH
L506 1-412-548-31 INDUCTOR 820UH
L507 1-414-856-11 INDUCTOR 10UH
L508 1-419-198-21 COIL, HORIZONTAL LINEARITY
L509 1-419-198-21 COIL, HORIZONTAL LINEARITY
L510 1-416-367-11 COIL, HORIZONTAL CENTER
L511 1-414-187-11 INDUCTOR 47UH
L513 1-414-856-11 INDUCTOR 10UH
L602 1-412-529-11 INDUCTOR 22UH
L603 1-412-537-31 INDUCTOR 100UH
L604 1-406-665-11 INDUCTOR 100UH
L606 1-249-377-11 CARBON 0.47 5% 1/4W F
