REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
6550-23N/23S/33N/63N/63S/73N
(d)
7-7
L652 1-419-177-11 INDUCTOR (33N, 73N)
<FILTER>
LF602¡1-429-180-41 TRANSFORMER, LINE FILTER
<TRANSISTOR>
Q501 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q502 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q503 8-729-048-61 TRANSISTOR 2SK2843LBS2SONY
Q504 8-729-031-89 TRANSISTOR 2SC3941A-Q(TA)
Q505 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q506 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q507 8-729-049-17 TRANSISTOR 2SC5302-SONY-CC
Q508 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q510 8-729-046-60 TRANSISTOR 2SK2605LBSONY
Q511 8-729-042-34 TRANSISTOR IRFU110A
Q512 8-729-047-72 TRANSISTOR 2SK3155-01
Q513 8-729-043-41 TRANSISTOR 2SK2098-01MR-F119
Q514 8-729-047-72 TRANSISTOR 2SK3155-01
Q515 8-729-047-72 TRANSISTOR 2SK3155-01
Q516 8-729-047-72 TRANSISTOR 2SK3155-01
Q518 8-729-301-46 TRANSISTOR 2SC2610
Q519 8-729-029-68 TRANSISTOR DTC114TSA
Q520 8-729-048-51 TRANSISTOR 2SJ516LBS2SONY
Q521 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q522 8-729-043-32 TRANSISTOR PDTA114EK-115
Q524 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q525 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q601 8-729-029-92 TRANSISTOR DTC143ESA
Q602 8-729-048-61 TRANSISTOR 2SK2843LBS2SONY
Q603 8-729-043-27 TRANSISTOR PDTC114EK-115
Q604 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q605 8-729-043-27 TRANSISTOR PDTC114EK-115
Q903 8-729-120-28 TRANSISTOR 2SC1623-L5L6
<RESISTOR>
R401 1-249-381-11 CARBON 1 5% 1/4W F
R402 1-215-866-11 METAL OXIDE 330 5% 1W F
R403 1-214-661-21 METAL 1.5 1% 1/4W
R404 1-216-669-11 METAL CHIP 5.6K 0.50%1/10W
R405 1-214-661-21 METAL 1.5 1% 1/4W
R406 1-216-677-11 METAL CHIP 12K 0.50%1/10W
R407 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R408 1-216-073-00 RES,CHIP 10K 5% 1/10W
R409 1-216-669-11 METAL CHIP 5.6K 0.50%1/10W
R410 1-216-677-11 METAL CHIP 12K 0.50%1/10W
R500 1-249-377-11 CARBON 0.47 5% 1/4W F
R501 1-216-025-91 RES,CHIP 100 5% 1/10W
R502 1-218-758-11 METAL CHIP 180K 0.50%1/10W
R503 1-216-675-91 METAL CHIP 10K 0.50%1/10W
R504 1-249-377-11 CARBON 0.47 5% 1/4W F
R505 1-216-073-00 RES,CHIP 10K 5% 1/10W
R506 1-215-481-00 METAL 330K 1% 1/4W
R507 1-215-431-00 METAL 2.7K 1% 1/4W
R508 1-247-807-31 CARBON 100 5% 1/4W
R509 1-247-863-91 CARBON 22K 5% 1/4W
R510 1-215-437-00 METAL 4.7K 1% 1/4W
R511 1-249-381-11 CARBON 1 5% 1/4W F
R512 1-249-389-11 CARBON 4.7 5% 1/4W
R513 1-215-888-00 METAL OXIDE 220 5% 2W F
R514 1-216-081-00 RES,CHIP 22K 5% 1/10W
R515 1-249-417-11 CARBON 1K 5% 1/4W F
R516 1-214-844-81 METAL 150 1% 1/2W
R517 1-216-393-00 METAL OXIDE 2.2 5% 3W F
R518 1-216-393-00 METAL OXIDE 2.2 5% 3W F
R519 1-215-463-00 METAL 56K 1% 1/4W
R520 1-249-397-11 CARBON 22 5% 1/4W F
R521 1-249-417-11 CARBON 1K 5% 1/4W F
R522 1-249-401-11 CARBON 47 5% 1/4W
R523 1-215-463-00 METAL 56K 1% 1/4W
R524 1-215-463-00 METAL 56K 1% 1/4W
R525 1-249-417-11 CARBON 1K 5% 1/4W F
R527 1-249-429-11 CARBON 10K 5% 1/4W
R528 1-216-081-00 RES,CHIP 22K 5% 1/10W
R529 1-249-429-11 CARBON 10K 5% 1/4W F
R530 1-216-474-11 METAL OXIDE 82 5% 3W F
R531 1-216-474-11 METAL OXIDE 82 5% 3W F
R532 1-249-385-11 CARBON 2.2 5% 1/4W F
R533 1-249-417-11 CARBON 1K 5% 1/4W F
R534 1-249-405-11 CARBON 100 5% 1/4W F
R535 1-215-463-00 METAL 56K 1% 1/4W
R536 1-249-417-11 CARBON 1K 5% 1/4W F
R537 1-215-463-00 METAL 56K 1% 1/4W
R538 1-215-905-11 METAL OXIDE 10 5% 3W F
R539 1-215-905-11 METAL OXIDE 10 5% 3W F
R540 ¡ 1-215-476-91 METAL 200K 1% 1/4W
R541 1-215-421-00 METAL 1K 1% 1/4W
R542 1-215-421-00 METAL 1K 1% 1/4W
R543 1-249-389-11 CARBON 4.7 5% 1/4W F
R544 1-247-903-00 CARBON 1M 5% 1/4W
R545 1-216-691-11 METAL CHIP 47K 0.50%1/10W
R546 1-215-457-00 METAL 33K 1% 1/4W
R547 1-215-477-00 METAL 220K 1% 1/4W
R548 1-215-423-00 METAL 1.2K 1% 1/4W
R549 1-215-464-00 METAL 62K 1% 1/4W
R550 1-215-423-00 METAL 1.2K 1% 1/4W
R551 1-216-687-11 METAL CHIP 33K 0.50%1/10W
R552 1-215-463-00 METAL 56K 1% 1/4W
R553 1-216-698-11 METAL CHIP 91K 0.50%1/10W
R554 1-218-756-11 METAL CHIP 150K 0.50%1/10W
R556 1-216-691-11 METAL CHIP 47K 0.50%1/10W
R557 1-216-079-00 RES,CHIP 18K 5% 1/10W
R558 1-216-671-11 METAL CHIP 6.8K 0.50%1/10W
R559 1-216-661-11 METAL CHIP 2.7K 0.50%1/10W
R560 1-216-679-11 METAL CHIP 15K 0.50%1/10W
R561 1-216-474-11 METAL OXIDE 82 5% 3W F
R562 1-215-451-00 METAL 18K 1% 1/4W
R563 1-249-383-11 CARBON 1.5 5% 1/4W F
R564 1-216-089-91 RES,CHIP 47K 5% 1/10W
