The FC 5289 and FC 5290 are 2-port EIA-232 asynchronous serial communications PCI Express (PCIe)
adapters that can be installed in the PCIe slots. The adapters are based on the PCIe 1.1 host bus interface.
The parallel port function is not implemented on these adapters.
Each of the two universal asynchronous receiver/transmitter (UART) channels contain 128 byte
receiver-transmitter, first-in first-out (FIFO), full modem-control signaling, and standard host interrupts. If
either of the two UART interrupts are active, the host can be interrupted through a single PCI interrupt.
The two-port adapter provides RJ45 Ethernet ports, which are connected by DB-9 connectors.
For details about slot priorities and placement rules, see the PCI adapter placement topic collection for
your system.
Specifications
Item Description
Adapter FRU number
74Y4085 (Designed to comply with RoHS requirement)
I/O bus architecture
PCIe 1.1
Slot requirement
For the slot priorities, see the PCI adapter placement topic collection for your system.
Cables
Cat 5 unshielded twisted-pair cables
Voltage
3.3 V
Form factor
Short
Maximum number
For the maximum adapters supported, see the PCI adapter placement topic collection for your
system.
Operating system or partition requirements
This adapter is supported for the following versions of the operating systems:
v AIX:
– AIX 7.1 with the 7100-01 Technology Level, or later
– AIX 6.1 with the 6100-07 Technology Level, or later
– AIX 5.3 with the 5300-12 Technology Level, and Service Pack 5, or later
v Linux:
– SUSE Linux Enterprise Server 11 SP1, or later
– SUSE Linux Enterprise Server 10 SP4, or later
– Red Hat Enterprise Linux Version 6.1, or later
– Red Hat Enterprise Linux Version 5.7, or later
– For support details, see the Linux Alert website (www14.software.ibm.com/webapp/set2/sas/f/
lopdiags/info/LinuxAlerts.htm)
v IBM i:
– IBM i Version 7.1, or later
If you are installing a new feature, ensure that you have the software that is required to support the new
feature and that you determine whether there are any prerequisites for this feature and attaching devices.
To check for the prerequisites, see IBM Prerequisite website (www-912.ibm.com/e_dir/eServerPrereq.nsf).
Related tasks:
Installing PCI adapters
Managing PCI adapters 11
