When using the Fibre Channel function, check the zoning and LUN assignments to ensure that the Fibre
Channel function is operating as expected.
Related tasks:
Installing PCI adapters
Related reference:
IBM Prerequisite website
Parts information
PCI adapter placement
“Backplane daughter cards and RAID enablement cards” on page 2
Find links to topics that cover Backplane daughter cards and RAID enablement cards.
PCIe LP 4-Port 10/100/1000 Base-TX Ethernet Adapter (FC 5271; CCIN
5717)
Learn about features, requirements, and specifications for the feature code (FC) 5271 adapter.
There are two adapters with the same CCIN. The feature code (FC) 5271 and FC 5717 are both the same
adapter. FC 5271 is a low-profile adapter and the FC 5717 is a full-height adapter. The names of these two
adapters are:
v FC 5271: PCIe LP 4-Port 10/100/1000 Base-TX Ethernet Adapter
v FC 5717: 4-Port 10/100/1000 Base-TX PCI Express Adapter
The PCIe LP 4-Port 10/100/1000 Base-TX Ethernet Adapter is a PCI Express (PCIe), low-profile, four
ported, Gigabit Ethernet adapter that can be configured to run either port at 1000, 100, or 10 Mbps data
rate. This adapter interfaces to the system through a PCIe bus and connects to a network using a 4-pair
CAT-5 Unshielded Twisted Pair (UTP) cable for distances of up to 100 meters. The adapter conforms to
the IEEE 802.3ab 1000Base-T standard. The 5717 also supports jumbo frames when running at the 1000
Mbps speed.
The adapter provides the following features:
v Supports interrupt moderation to deliver increased performance while significantly reducing central
processing unit (CPU) utilization
v Allows quad-port operation in x4, x8, x16 slots, and each port operates without interfering with the
other
v Each port operates without interfering with the other
v Auto-negotiation, full-duplex (half-duplex available for 10/100)
v Integrated media access control (MAC) and physical layer (PHY)
v Supports Fast EtherChannel (FEC) and Gigabit EtherChannel (GEC) when used with capable switch
v Supports IEEE 802.3ad Link Aggregation control protocol when used with capable switch
v IEEE 802.1Q VLANs, IEEE 802.3 (z, ab, u, x) flow control support, IEEE 802.1p
v TCP checksum offload -- transmission control protocol (TCP), Internet Protocol (IP) for IPv4
v TCP Segmentation Offload (TSO) / Large Send Offload (LSO)
v Bus width x4 lane; operable in x4, x8, or x16 slots
v Bus speed (x4, encoded rate) 10 Gbps unidirectional and 20 Gbps bidirectional
v EEPROM SPI and single EEPROM support
v Interrupt levels INTA and MSI (requires system and software support for MSI)
v IEEE 802.3ab
v Hardware certifications FCC B, UL, CE, VCCI, BSMI, CTICK, MIC
82 Power Systems: Managing PCI adapters for the IBM Power 710 Express or the IBM Power 730 Express
