Parts information
PCI adapter placement
“Backplane daughter cards and RAID enablement cards” on page 2
Find links to topics that cover Backplane daughter cards and RAID enablement cards.
10 Gigabit Ethernet-CX4 PCI Express Adapter (FC 5732; CCIN 5732)
Learn about the features, operating system requirements, and installation procedures for the feature code
(FC) 5732 adapter.
Overview
The 10 Gigabit Ethernet-CX4 PCI Express (PCIe) Adapter is a low-profile, high performance CX4 copper
network interface controller (NIC). The product conforms to the IEEE, 802.3ae 10GBASE-CX specification
for Ethernet transmission. 10GBase-CX4 uses the XAUI (10 Gigabit attachment unit interface) specified in
802.3ae, and the 4X connector that is used for InfiniBand technology. The adapter is used to connect
servers or switches over short distances of up to 15 meters.
The following figure shows the adapter.
The LED on the adapter provides information about the operation status of the adapter.
Table 37. Adapter LED
LED Light Description
Activity/Link Green Good link, no activity
Flashing Transmit activity
Off No link
*
Figure 42. 10 Gigabit Ethernet-CX4 PCI Express (PCIe) Adapter
120 Power Systems: Managing PCI adapters for the IBM Power 710 Express or the IBM Power 730 Express
