Technical Specifications
System component Description
ANSI Fibre Channel
protocol
FC-PH (Fibre Channel Physical and Signaling Interface standard)
Modes of operation Fibre Channel Class 2 and Class 3
Fabric initialization Complies with FC-SW-3 Rev. 6.6
FCIP (IP over Fibre
Channel)
Complies with FC-IP 2.3 of FCA profile
Port Status Bicolor LED (amber/green)
Other
System component Description
Serial console port One three-wire (Tx, Rx, Gnd) UART serial port
Ethernet management port One 1000Base-X / 100Base-TX port / 10Base-T
USB port One external USB port
LEDs
System component Description
System power LED One green system power status LED (below) on the port side.
System status LED One bicolor (green/amber) system status LED (above) on the port side.
Ethernet port link LED One link LED on the left. Glows green for 1000 Mbps and amber for 100/10 Mbps.
Serial console port LED The serial console port LEDs remain off at all times, even when a cable is inserted
and the link is active.
FC port status LED 64 bicolor (green/amber) port status LEDs. One for each SFP+ port and four for
each QSFP port on the switch.
Power supply and fan
assembly status LED
One green power supply and fan assembly status LED on each power supply and
fan assembly on the nonport-side of the switch.
84 Hardware Installation Guide
