4.39 cm
1.73 inches
44.00 cm
17.32 inches
35.56 cm
14.00 inches
7.71 kg
17.00 lb
8.53 kg
18.80 lb
Technical Specifications
Other
System component Description
Serial cable RJ-45 console cable
RJ-45 to DB9 adapter RJ-45 to DB9 for console cable
RJ-45 connector Uses an RJ-45 connector for the serial port
Weight and physical dimensions
Empty weight refers to the device with two power supply and fan assemblies installed but no SFP+ or
QSFP transceivers.
Model
Switch
Environmental requirements
Condition Operational Non-operational
Ambient temperature 0°C to 40°C (32°F to 104°F) -25°C to 70°C (-13°F to 158°F)
Relative humidity
(non-condensing)
10% to 85% at 40°C (104°F) 10% to 90% non-condensing
Altitude (above sea
level)
0 to 3000 m (9,842 feet) 0 to 12000 m (39,370 feet)
Shock 20.0 G, 6 ms, half-sine wave 33.0 G, 11 ms, half-sine wave, 3/eg Axis
Vibration 0.5 G sine, 0.4 gms random, 5-500 Hz 2.0 G sine, 1.1 gms random, 5-500 Hz
Airflow Maximum: 71.36 cmh (42 cfm)
Nominal: 59.47 cmh (35 cfm)
N/A
Heat dissipation 716 BTU/hr for 64 ports N/A
Operating noise 65 dB N/A
Hardware Installation Guide 85
