Technical Specifications
Port speed
(Gbps)
Cable size
(microns)
Short wavelength (SWL) Long wavelength
(LWL)
Extended long
wavelength (ELWL)
9 N/A 10 km (6.2 miles) N/A
16 50 35 m (115 ft) (OM2)
100 m (328 ft) (OM3)
125 m (410 ft) (OM4)
N/A N/A
62.5 15 m (49 ft) N/A N/A
9 N/A 10 km (6.2 miles) N/A
32 50 70 m (230 ft) (OM3)
100 m (328 ft) (OM4)
N/A N/A
62.5 N/A N/A N/A
9 N/A 10 km (6.2 miles) N/A
Serial port specifications (pinout RJ-45)
Pin Signal Description
1 Not supported N/A
2 Not supported N/A
3 UART1_TXD Transmit data
4 GND Logic ground
5 GND Logic ground
6 UART1_RXD Receive data
7 Not supported N/A
8 Not supported N/A
Serial port specifications (protocol)
Parameter Value
Baud 9600
88 Hardware Installation Guide
