Technical Specifications
Model name @100 VAC
input
@200 VAC
input
@-48 VDC input Minimum number
of power supplies
Notes
Switch
85 W
Not supported
Not supported
1
No optics or connections to ports
installed and system booted up. Fans at
nominal speed.
Data port specifications (Fibre Channel)
Name Port
Numbers
Media Type Description
Switch 0 to 47 10-, 16-, or 32-Gbps SFP+
optical ports
48 to 63 4 x 16- or 32-Gbps (64 or 128
Gbps) QSFP optical ports
Can be an F_Port, N_Port, E_Port, or EX_Port
Can be an E_Port or EX_Port
Fibre Channel data transmission ranges
Port speed
(Gbps)
Cable size
(microns)
Short wavelength (SWL) Long wavelength
(LWL)
Extended long
wavelength (ELWL)
4
50
150 m (492 ft) (OM2)
380 m (1,264 ft) (OM3)
400 m (1,312 ft) (OM4)
N/A
N/A
62.5
70 m (229 ft)
N/A
N/A
9
N/A
30 km (18.6 miles)
N/A
8
50
50 m (164 ft) (OM2)
150 m (492 ft) (OM3)
190 m (623 ft) (OM4)
N/A
N/A
62.5
21 m (68 ft)
N/A
N/A
9
N/A
10 km (6.2 miles)
N/A
10
50
82 m (269 ft) (OM2)
300 m (984 ft) (OM3)
550 m (1,804 ft) (OM4)
N/A
N/A
62.5
33 m (108 ft)
N/A
N/A
Hardware Installation Guide 87
