IBM Aptiva 2158

Parts/Test Point Locations 133
N= On, F=Off
Machine Type 2158 Processor Type Jumper Settings
NOTE:
You must verify the exact processor type before setting the processor type
jumpers. The wrong processor type jumper setting may damage the CPU. The
system only supports dual-voltage CPU
CPU SW1 SW2 SW3
Switch 2 3 4 3 4 12345678
K6-2 333MHz
(Host=95MHz)
N F F F N FFFFFFNF
K6-2 350MHz
(Host=100MHz)
F F F N N FFFFFFNF
K6-2XT 350MHz
(Host=100MHz)
F F F N N FFFFFFNF
K6-2XT 380MHz
(Host=95MHz)
N F F F N NFNFFFNF
K6-2XT 400MHz
(Host=100MHz)
F F F N N NFNFFFNF
K6-2XT 450MHz
(Host=100MHz)
FFFNNNNNFFFNF
