Parts/Test Point Locations 143

3.5-In Maxtor Hard Disk

3.5-In Maxtor Hard Disk Drive Jumper Settings

J50 Description

On Drive configured as a Master or

Drive configured as a Master, with an attached Slave

Off Drive configured as a Slave.
