IBM Aptiva 2170 User Manual

164
The configuration of the following jumpers controls the drive's mode of
operation:
•
SP - Slave Present
•
DS - Drive Select
•
CS - Cable Select
3.5-In Seagate Hard Disk
3.5-In Seagate Hard Disk Drives Jumper Settings
DS CS/SP Description
On Off Master or Single Drive
Off Off Drive is Slave.
On On Master with a non-ATA compatible Slave
Off On Cable Select
