IBM Aptiva 2172

163
3.5-In. Hard Disk Drive Jumper Settings
The configuration of the following jumpers controls the drive's mode of
operation:
•
DS - Drive Select (For Master only)
•
CS - Cable Select
•
PK - Park, used as a place to store a jumper
3.5-In Quantum Fireball Series Hard Disk
