9.1.2.2 Synchronous Negotiation Started by the Target
If the file recognizes that negotiation is required, the file sends a SDR message to the initiator with minimum
transfer period on the current receiver mode. The file interprets the Initiator corresponding transfer period as
shown in the following figure Figure 129 on page 166:
9.1.2.2.1 On LVD receiver mode.
Target Maximum
Initiator's Transfer Burst
Response Period Rate
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ ÄÄÄÄÄÄÄÄÄÄ ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ
0 <= Mi <= 09 Send Message Reject(Async mode) N/A
10 <= Mi <= 10 25 nSec 40.00 MT/s
11 <= Mi <= 11 50 nSec 20.00 MT/s
12 <= Mi <= 12 50 nSec 20.00 MT/s
13 <= Mi <= 18 75 nSec 13.33 MT/s
19 <= Mi <= 25 100 nSec 10.00 MT/s
26 <= Mi <= 31 125 nSec 8.00 MT/s
32 <= Mi <= 37 150 nSec 6.67 MT/s
38 <= Mi <= 43 175 nSec 5.71 MT/s
44 <= Mi <= 50 200 nSec 5.00 MT/s
51 <= Mi <= 56 225 nSec 4.44 MT/s
57 <= Mi <= 62 250 nSec 4.00 MT/s
63 <= Mi <= 68 275 nSec 3.64 MT/s
69 <= Mi <= 75 300 nSec 3.33 MT/s
76 <= Mi <= 81 325 nSec 3.08 MT/s
82 <= Mi <= 87 350 nSec 2.86 MT/s
88 <= Mi <= 93 375 nSec 2.67 MT/s
94 <= Mi <= 100 400 nSec 2.50 MT/s
101 <= Mi <= 106 425 nSec 2.35 MT/s
107 <= Mi <= 255 Send Message Reject(Async mode) N/A
Figure 129. Target Response to Initiator's Transfer Period(LVD mode)
9.1.2.2.2 F-20 mode.
166 OEM Spec. of DDRS-3xxxx
