IBM FlashSystem 710 and IBM FlashSystem 810 6
Models
Table 2 lists the FlashSystem 710 and FlashSystem 810 models.
Table 2. Models
Description Machine type-model
IBM FlashSystem 710 9830-AS1
IBM FlashSystem 810 9830-AE1
The FlashSystem 710 and FlashSystem 810 storage systems are shipped with the following items:
Statement of Limited Warranty
z
Quick start guide
z
Documentation CD containing
Installation and User's Guide
z
Fixed mount rail kit
z
Two IEC 320-C13 to C14 rack PDU power cords
z
The FlashSystem 710 and FlashSystem 810 storage systems require interface and flash modules to be
ordered with the base model. See "Interface modules" and "Flash modules" sections for details.
Interface modules
FlashSystem 710 and FlashSystem 810 support either 8 Gb Fibre Channel (FC) or 40 Gbps InfiniBand
connectivity with the interface modules shown in Table 3 (only one feature can be selected).
Table 3. Supported interface modules
Description Feature code
Maximum quantity
supported
8 Gb FC 4 Port Ext Int AF04 1
IB QDR 4 Port Ext Int AF05 1
Each interface module feature code contains two dual-port cards (either 8 Gb Fibre Channel or QDR
InfiniBand) for a total of four ports in the system. FC interface modules come standard with four (one per
each port) 8 Gb FC shortwave SFP+ transceivers with LC duplex connector. InfiniBand interface modules
have QSFP receptacles.
FC interfaces support Fibre Channel Protocol (FCP) only, with point-to-point (FC-P2P), arbitrated loop
(FC-AL), and switched fabric (FC-SW) topologies. FC interfaces can be configured as N
port or NL
port
types. InfiniBand interfaces support SCSI RDMA Protocol (SRP) only. Dual-port interface modules
support full active-active load balancing and failover multi-pathing, though host software support for this
function can vary.
