1. Turn off the computer and all attached devices. Disconnect all external cables
and power cords; then, remove the side cover. See “Removing the side cover”
on page 26.
2. Use a screwdriver to remove the two metal knockouts.
3. Insert the rope clip through the rear panel; then, attach and tighten the nuts.
4. Thread the cable through the rope clip and around an object that is not part of
or permanently secured to the building structure or foundation, and from which
the cable cannot be removed. Fasten the cable ends together with a lock. After
you add the security cable, be certain it does not interfere with other cables
connected to the computer.
Rope clip
5. If you have other options to install or remove, do so now; otherwise, go to
“Completing the installation” on page 40.
Chapter 2. Installing the hardware 39
