IBM L150 User Manual

IBM 15” Service Manual
10
Addressability Vt. Frequency (Hz)
640 x 350 70
640 x 480 60
640 x 480 66
640 x 480 72
640 x 480 75
720 x 400 70
800 x 600 60
800 x 600 72
800 x 600 75
1024 x 768 60
1024 x 768 70
1024 x 768 75
IBM MODES
Horizontal Vertical
Mode Resolution Total
Nominal
Frequenc
y
+/-
0.5kHz
Sync
Polarit
y
Nomina
l
Freq.
+/- 1 Hz
Sync
Polarity
Nominal
Pixel
Clock
(MHz)
DOS*
720x400@70
Hz
900 x 449 31.469 N 70.087 P 28.322
DOS*
*
640x350@70
Hz
800 x 449 31.469 N 70.087 P 25.175
MAC MODES
VGA 640x480@67
Hz
864x525 35.000 N 66.667 N 30.240
SVGA 832x624@75
Hz
1152x667 49.725 N 74.551 N 57.2832
