IBM 15” Service Manual
38
8.2.3 KeyPad Board
OSD is unstable or not working
Is KeyPad Board connecting normally ?
Connect KeyPad Board
Is Button Switch normally ?
Replace Button Switch
Y
N
N
Is KeyPad Board Normally ?
Replace KeyPad Board
Y
N
Y
Check Main Board
