3. Replace the two cover screws (2) at the rear of the cover.
Service and operating positions for the 7063-CR1 system
Learn how to place an IBM 7063-CR1 Hardware Management Console system into the service or
operating position.
Placing a 7063-CR1 system into the service position
Learn how to place an IBM 7063-CR1 Hardware Management Console system into the service position.
Before you begin
The systems must be removed from the rails for servicing.
CAUTION:
or
or
The weight of this part or unit is between 18 and 32 kg (39.7 and 70.5 lb). It takes two persons to
safely lift this part or unit. (C009)
Notes:
v When you slide a system out of a rack, ensure that all stability plates are firmly installed to prevent the
rack from toppling. Slide only one system out at a time.
Figure 68. Replacing and securing the cover
Common procedures for servicing the 7063-CR1 77
