IBM SAS RAID controllers User Manual

Viewing the active or passive path role for a controller
To view the active or passive path role for a controller, complete the following steps.
1. Select Start a service tool on the Use System Service Tools (SST) menu.
2. Select Hardware service manager on the Start a Service Tool menu.
3. Select Logical hardware resources (buses, IOPs, controllers) on the Hardware Service Manager menu.
4. Select System bus resources on the Logical Hardware Resources on the System Bus menu.
5. Select the Virtual IOP by typing a 9 (Resources associated with IOP) in front of the desired IBM dual
storage IOA.
6. Press F11 (function key) until Path Role is shown.
Logical Hardware Resources Associated with IOP
Type options, press Enter.
2=Change detail 4=Remove 5=Display detail 6=I/O debug
7=Verify 8=Associated packaging resource(s)
Resource
Opt Description Type-Model Path Role Name
Virtual IOP * 572F-001 CMB01
Storage IOA 572F-001 DC02
Disk Unit 433B-099 Active DMP002
Disk Unit 433B-099 Passive DMP004
Disk Unit 433B-099 Active DMP006
Disk Unit 433B-099 Passive DMP008
Disk Unit 433B-099 Active DMP010
Disk Unit 433C-099 Active DMP012
Disk Unit 433C-099 Active DMP014
Disk Unit 433C-099 Passive DMP016
Disk Unit 433B-099 Passive DMP018
More...
F3=Exit F5=Refresh F6=Print F8=Include non-reporting resources
F9=Failed resources F10=Non-reporting resources
F11=Display status/resource name F12=Cancel
Related concepts:
“Dual storage IOA functions” on page 23
Consider these factors when using dual storage I/O adapter (IOA) functions.
“Installing dual storage IOA configurations”
Use this procedure to install a dual storage I/O adapter (IOA) configuration.
Related information:
Changing parity set optimization
Installing dual storage IOA configurations
Use this procedure to install a dual storage I/O adapter (IOA) configuration.
To avoid problems during installation, follow the steps exactly as written.
Attention: Disk arrays can be created either before or after the dual storage IOA configuration is set up.
Each storage adapter requires a supported release of IBM i and other possible code prerequisites. Go to
the IBM Prerequisites website and click the Feature Prerequisites tab.
Attention: Ensure that the adapters are updated with the latest adapter microcode, which is available as
a program temporary fix (PTF) as part of the initial installation.
To install a dual storage IOA configuration, complete the following steps:
1. Verify that all prerequisites are permanently applied.
30 SAS RAID controllers for IBM i
