Table 3. 7042-CR6 parts listing (continued)
Index Description Tier 1
CRU
Tier 2
CRU
Part number
17 Hard disk drive, 2.5-inch hot-swap, 73 GB, 15 K 43W7546
17 Hard disk drive, 2.5-inch hot-swap, 146 GB, 10 K 43W7538
17 Hard disk drive, 2.5-inch hot-swap, 146 GB, 15 K 42D0678
17 Hard disk drive, 2.5-inch hot-swap, 146 GB, Slim-HS, 15 K 44W2295
17 Hard disk drive, 2.5-inch hot-swap, 300 GB, 10 K 42D0638
17 Hard disk drive, 2.5-inch hot-swap, 300 GB, Slim-HS, 10 K 44W2265
17 Hard disk drive, 2.5-inch hot-swap, 500 GB, 10 K 42D0708
17 Hard disk drive, 2.5-inch hot-swap, 600 GB, 10 K 49Y2004
18 Backplate assembly, simple-swap 59Y3919
19 Backplane, SAS 59Y3915
20 Fan 43V6929
21 System board 59Y3793
22 ServeRAID-M1015 adapter (models B2x, C2x, D2x, H2x, and N2x) 46M0861
23 ServeRAID-BR10il v2 adapter (model A2x) 49Y4737
24 SAS/SATA riser card 43V7067
25 Retention module, heat sink 49Y4822
26 Microprocessor, 1.86 GHz 40W 69Y0783
26 Microprocessor, 2.13 GHz 40W (model C2x) 59Y3691
26 Microprocessor, 2.13 GHz 80W (model A2x) 46D1270
26 Microprocessor, 2.26 GHz 80W (model B2x) 69Y0782
26 Microprocessor, 2.26 GHz 60W (model H2x) 49Y7054
26 Microprocessor, 2.40 GHz 80W (model D2x) 49Y7053
26 Microprocessor, 2.53 GHz 80W (model F2x) 49Y7052
26 Microprocessor, 2.66 GHz 80W (model G2x) 49Y7051
26 Microprocessor, 2.66 GHz 95W (model J2x) 49Y7040
26 Microprocessor, 2.93 GHz 95W (model M2x) 49Y7038
26 Microprocessor, 3.33 GHz 130W (model N2x) 69Y0849
27 Heat sink assembly (models A2x, B2x, C2x, D2x, F2x, G2x, H2x, J2x,
and M2x)
49Y4820
27 Heat sink assembly, 130W (model N2x) 69Y1207
28 Air baffle kit (Microprocessor air baffle, clamp, and DIMM air duct)
(all models)
59Y3914
29 DIMM air duct 43V7050
The 7042-CR6 parts that are listed in the following table are not illustrated.
Table 4. 7042-CR6 parts listing (continued)
Description Tier 1
CRU
Tier 2
CRU
Part number
Cable, hard disk drive configuration 59Y3918
Cable, operator panel 46C4139
8 Troubleshooting, service, and support using SDMC
