▌1▐ Power
▌2▐ Status
▌3▐ Fault
The canister is ready with no critical errors when Power is illuminated, Status
is flashing, and Fault is off. If a canister is not ready, refer to the “Procedure:
Understanding the system status using the LEDs” topic in “Troubleshooting”.
Figure 26. Node canister LEDs
Chapter 2. Installing the hardware 29
