▌1▐ Slide rail kit
▌2▐ Cable management arm
▌3▐ Fascia
Other parts, such as the cover, secondary expander modules, and fans, are installed
in the enclosure. However, due to weight considerations, you must remove some
parts and then reinstall them as part of the initial installation process.
Note: Drives are not included in installation package for the enclosure; they are
provided in a separate package.
Procedure
1. Remove the cardboard tray that contains the slide rails, cable management
arm, and fascia from cardboard box in which the expansion enclosure was
shipped.
2. Remove the foam end pieces from the top of the 2077-92F expansion
enclosure.
3. Cut the corners of the shipping box and fold them down to uncover the sides
and faces of the expansion enclosure, as shown in Figure 28.
▌1▐ Enclosure
▌2▐ Top of shipping box, folded back.
▌3▐ Foam protectors
4. Remove the top cover, as described in “Removing the top cover: 2077-92F” on
page 48.
5. With two or more persons, push the expansion enclosure sideways onto an
adjacent flat bed lift. Keep the remaining foam block protectors attached to the
enclosure.
6. Remove the support rail kit from the box in which it was shipped (▌1▐, as
shown in Figure 27 on page 45).
Figure 28. Packaging materials
46 Storwize V5000 Gen2: Quick Installation Guide
