5. Remove the paper door assembly:
a. Remove the long leg of the lift spring (B in Figure 33 on page 60) from the mounting slot.
b. Rotate the spring until short leg of the spring is no longer in contact with the paper door; then,
remove the spring from the post.
A
Figure 32. Cutter motor screws
Removing and replacing FRUs
Chapter 5. Removing and replacing FRUs 59
