Asm–
Index
Part
Number Units Description
1– 73Y1158 1 Model 1NR, 80 mm pearl white covers without interface card
– 73Y1159 1 Model 1NR, 80 mm, iron gray covers, without interface card
– 84Y0539 Model 1NR, fiscal ready,80 mm pearl white covers without fiscal drawer assembly
– 84Y0540 Model 1NR, fiscal ready,80 mm iron gray covers without fiscal drawer assembly
–
–1 73Y1197 1 Fiscal base assembly, pearl white
–1 73Y1198 1 Fiscal base assembly, iron gray
–
–2 84Y0527 1 Cable cover, pearl white
–2 84Y0528 1 Cable cover, iron gray
–
–3 50Y0020 1 Interface card, USB/RS-232, 24V
–
–4 50Y0090 1 Low paper motion sensor assembly
– 50Y0086 1 v Paper motion sensor
– 50Y0088 1 v Paper motion sensor cable
–
–5 50Y0064 1 Logic card, base
–
–6 50Y0092 1 Paper transport frame
Includes frame, paper advance motor, printhead, tearbar, stationary cutter, gears,
wall mount drag strip, and mounting screw
– Includes inner cover, platen, cutter motor, top cutter blade, cutter sensor, drag
strip, and cover open springs.
–7 80Y1281 1 Paper motion sensor assembly
Includes sensor and cable
–
–8 60Y3083 1 Paper door assembly, 80 mm
–
–9 60Y3165 1 Mid cover, pearl white
–9 60Y3172 1 Mid cover, iron gray
–10 50Y0071 1 paper door cover, pearl white
–10 50Y0076 1 paper door cover, iron gray
–
–11 60Y3153 1 Spill cover, pearl white
–11 60Y3155 1 Spill cover, iron gray
–
– 13G2015 1 RS-232 Cable, 3 foot length Null modem (not shown)
– 07K5155 1 Powered USB Display cable 1.8M (not shown)
– 40N6723 1 Power supply (not shown)
– 50Y0082 1 Paper bucket roller kit (6 rollers, not shown)
– 50Y0084 1 Miscellaneous parts kit (not shown)
Includes screws, clips, springs, ground straps, and drag strip.
– 50Y0096 1 Printhead with screws (not shown)
– 50Y0094 1 Thermal printhead flat cable (not shown)
– 60Y3168 1 Flex circuit (not shown)
– 93F0415 1 Grease packet (not shown)
Assembly 1: (continued)
Appendix C. Parts listing 81
