Processor
Storage
Address
Bits
Bits
8-19,20
20-26
21-26
27-28
29-31
Used
for
address
compare
(16K,
8K
buffer)
Used
to
reference
16K
buffer
columns
Used
to
reference
SK
buffer
columns
Used
to
reference
doubleword
within
a
block
Used
to
reference
byte
within
doubleword
Figure
10.15.5.
Processor
storage
address
format
for
buffer
reference
Buffer
Reference
Bits
Bits
0-1
Generated
as
result
of
address
compare;
this
two-bit
encoded
field
represents
block
in
buffer
column
containing
desired
data
2-S
3-8
8-10
Used
to
reference
column
for
16K
buffer
(processor
storage
address
bits
20-26)
Used
to
reference
column
for
SK
buffer
(processor
storage
address
bits
21-26)
Used
to
reference
doubleword
within
a
block
(processor
storage
address
bits
27-2S)
Figure
10.15.6.
Buffer
address
format
Buffer
contents
and
buffer
block
assignment
are
controlled
by
an
address
array,
shown
in
Figure
10.15.4,
and
a
special
replacement
array.
The
address
array,
like
the
SK
buffer,
is
divided
into
64
columns
conSisting
of
four
block
address
registers
each"such
that
there
is
a
one-for-one
correspondence
between
address
array
registers
and
blocks
in
the
buffer.
An
address
array
block
register
contains
the
13-bit
processor
storage
block
address
from
bits
8-20
of
the
processor
storage
address
of
the
data
contained
in
its
corresponding
buffer
block.
When a
CPU
to
processor
storage
reference
is
made,
the
four
appropriate
address
array
column
registers
(13-bit
block
addresses)
are
interrogated
to
determine
whether
the
requested
data
is
currently
in
the
buffer.
The
replacement
array
is
used
to
maintain
knowledge
of
the
activity
of
the
data
blocks
within
each
of
the
buffer
columns.
When
an
8K
buffer
is
present,
the
array
consists
of
64
logic-controlled
activity
lists,
one
list
for
each
column
in
the
buffer.
A
list
contains
four
entries,
one
for
each
buffer
block
in
its
column.
A
block's
entry
is
plac'~d
at
the
top
of
the
list
for
its
column
when
the
buffer
block
is
referenced
during
a
CPU
fetch
operation.
This
approach
insures
that
the
block
used
longest
ago
within
a
given
column
is
at
the
bottom
of
the
list.
When a
block
within
a
buffer
column
has
to
be
assigned
and
loaded,
because
the
data
requested
by
the
CPU
is
not
in
the
buffer,
the
buffer
block
at
the
bottom
of
a
column
activity
list
is
allocated.
Thus,
the
more
active
data
is
maintained
in
the
buffer.
The
SK
buffer
operates
as
follows.
When
the
CPU
requests
data,
bits
21-26
of
the
data's
processor
storage
address
are
used
to
obtain
a
buffer
column
address.
The
13
high-order
bits
of
the
processor
storage
address
are
then
compared
to
the
address
in
each
of
the
four
block
address
registers
in
that
buffer
column
in
the
address
array.
23
