IBM System x3100 M4

Table 7. DSA Preboot messages (continued)
v Follow the suggested actions in the order in which they are listed in the Action column until the problem is solved.
v See Chapter 4, “Parts listing, System x3100 M4 Type 2582,” on page 151 to determine which components are customer
replaceable units (CRU) and which components are field replaceable units (FRU).
v If an action step is preceded by “(Trained service technician only),” that step must be performed only by a Trained
service technician.
v Go to the IBM support website at http://www.ibm.com/supportportal/ to check for technical information, hints, tips, and
new device drivers or to submit a request for information.
Message
number Component Test State Description Action
201-801-xxx Memory Memory Test Aborted Test canceled: the
system UEFI
programmed the
memory controller
with an invalid
CBAR address
1. Turn off and restart the system.
2. Run the test again.
3. Make sure that the server firmware is
at the latest level. The installed
firmware level is shown in the DSA
event log in the Firmware/VPD
section for this component. For more
information, see “Updating the
firmware” on page 267.
4. Run the test again.
5. If the failure remains, go to the IBM
website for more troubleshooting
information at http://www.ibm.com/
systems/support/supportsite.wss/
docdisplay?brandind=5000008
&lndocid=SERV-CALL.
201-802-xxx Memory Memory Test Aborted Test canceled: the
end address in the
E820 function is
less than 16 MB.
1. Turn off and restart the system.
2. Run the test again.
3. Make sure that all DIMMs are
enabled in the Setup utility.
4. Make sure that the server firmware is
at the latest level. The installed
firmware level is shown in the DSA
event log in the Firmware/VPD
section for this component. For more
information, see “Updating the
firmware” on page 267.
5. Run the test again.
6. If the failure remains, go to the IBM
website for more troubleshooting
information at http://www.ibm.com/
systems/support/supportsite.wss/
docdisplay?brandind=5000008
&lndocid=SERV-CALL.
126 IBM System x3100 M4 Type 2582: Problem Determination and Service Guide
