IBM System x3550 M3 User Manual

IBM System x3550 M3 17
The following table lists hard drive options for internal disk storage of x3550 M3 server.
Table 7. Disk drive options for internal disk storage (Part 1)
Part
number
Feature
code
Description Maximum
supported
Hot-Swap 15K SAS HDDs
81Y9670 A283 IBM 300GB 15K 6Gbps SAS 2.5" SFF HS HDD 8
42D0677 5536 IBM 146GB 15K 6Gbps SAS 2.5" SFF Slim-HS HDD 8
90Y8926 A2XB IBM 146GB 15K 6Gbps SAS 2.5" SFF G2HS HDD 8
Hot-Swap 10K SAS HDDs
81Y9650 A282 IBM 900GB 10K 6Gbps SAS 2.5" SFF HS HDD 8
49Y2003 5433 IBM 600GB 10K 6Gbps SAS 2.5" SFF Slim-HS HDD 8
90Y8872 A2XD IBM 600GB 10K 6Gbps SAS 2.5" SFF G2HS HDD 8
90Y8908 A3EF IBM 600GB 10K 6Gbps SAS 2.5" SFF G2HS SED 8
42D0637 5599 IBM 300GB 10K 6Gbps SAS 2.5" SFF Slim-HS HDD 8
90Y8877 A2XC IBM 300GB 10K 6Gbps SAS 2.5" SFF G2HS HDD 8
90Y8913 A2XF IBM 300GB 10K 6Gbps SAS 2.5" SFF G2HS SED 8
Hot-swap SAS SEDs
81Y9662 A3EG IBM 900GB 10K 6Gbps SAS 2.5" SFF G2HS SED 8
44W2264 5413 IBM 300GB 10K 6Gbps SAS 2.5" SFF Slim-HS SED 8
44W2294 5412 IBM 146GB 15K 6Gbps SAS 2.5" SFF Slim-HS SED 8
90Y8944 A2ZK IBM 146GB 15K 6Gbps SAS 2.5" SFF G2HS SED 8
Hot-Swap NL SAS HDDs
81Y9690 A1P3 IBM 1TB 7.2K 6Gbps NL SAS 2.5" SFF HS HDD 8
42D0707 5409 IBM 500GB 7200 6Gbps NL SAS 2.5" SFF Slim-HS HDD 8
90Y8953 A2XE IBM 500GB 7.2K 6Gbps NL SAS 2.5" SFF G2HS HDD 8
Hot-Swap NL SATA HDDs
81Y9730 A1AV IBM 1TB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD 8
42D0752 5407 IBM 500GB 7200 NL SATA 2.5" SFF Slim-HS HDD 8
81Y9726 A1NZ IBM 500GB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD 8
81Y9722 A1NX IBM 250GB 7.2K 6Gbps NL SATA 2.5" SFF HS HDD 8

IBM System x3550 M3 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1, 10
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	-
Total storage capacity	0 GB
Maximum storage capacity	8 TB
Number of HDDs installed	0
Internal memory	24 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	6 x 4 GB
Maximum graphics card memory	16 MB
Graphics card family	Matrox
Graphics card memory type	GDDR2
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Power supply	460 W
Power supply type	AC
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Compatible operating systems	Microsoft Windows Server 2008 R2 and 2008, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and VMware ESXi, Oracle Solaris 10 (model dependent)
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	8 - 80 %
Chassis type	Rack (1U)
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	711 mm
Width	440 mm
Height	43 mm
Weight	15600 g
