IBM System x3550 M3 18

Table 7. Disk drive options for internal disk storage (Part 2)

Part

number

Feature

code

Description Maximum

supported

Hot-Swap SATA SSDs

00W1125 A3HR IBM 100GB SATA 2.5" MLC HS Enterprise SSD 8

43W7718 A2FN IBM 200GB SATA 2.5" MLC HS SSD 8

49Y5839 A3AS IBM 64GB SATA 2.5" MLC HS Enterprise Value SSD 8

49Y5844 A3AU IBM 512GB SATA 2.5" MLC HS Enterprise Value SSD 8

90Y8643 A2U3 IBM 256GB SATA 2.5" MLC HS Enterprise Value SSD 8

90Y8648 A2U4 IBM 128GB SATA 2.5" MLC HS Enterprise Value SSD 8

Simple-Swap SATA SSDs*

00W1130* A3HS IBM 100GB SATA 2.5" MLC SS Enterprise SSD 4

49Y5849* A3AT IBM 64GB SATA 2.5" MLC SS Enterprise Value SSD 4

49Y5854* A3AV IBM 512GB SATA 2.5" MLC SS Enterprise Value SSD 4

90Y8663* A2UC IBM 256GB SATA 2.5" MLC SS Enterprise Value SSD 4

90Y8668* A2UB IBM 128GB SATA 2.5" MLC SS Enterprise Value SSD 4

* Simple-swap drives are only supported in CTO configurations with simple-swap drive bays

The following table lists the RAID controllers and additional options used for internal disk storage.

Table 8. RAID controllers for internal storage

Part

number

Feature

code

Description Maximum

supported

Models

where used

49Y4731 9742 ServeRAID-BR10il SAS/SATA Controller V2 1 A2x, 12x

81Y4492 A1XL ServeRAID H1110 SAS/SATA Controller 1 -

46M0831 0095 ServeRAID M1015 SAS/SATA Controller 1 B2x, C2x, D2x,

H2x, N2x, 22x,

32x, D4x

46M0832 9749 ServeRAID M1000 Series Advance Feature Key 1 -

46M0917 5744 ServeRAID M5000 Series Battery Kit 1 J2x, M2x, H4x,

J4x, 72x, 82x

46M0930 5106 ServeRAID M5000 Series Advanced Feature Key* 1 -

81Y4426 A10C ServeRAID M5000 Series Performance Accelerator Key* 1 -

46M0916 3877 ServeRAID M5014 SAS/SATA Controller 1 F2x, G2x, 52x,

54x, 62x

46M0829 0093 ServeRAID M5015 SAS/SATA Controller 1 J2x, M2x, H4x,

J4x, 72x, 82x

90Y4304 A2NF ServeRAID M5016 SAS/SATA Controller 1 -

46M0969 3889 ServeRAID B5015 SSD Controller 1 -

Questions and Answers:

Need help?

Do you have a question about the IBM System x3550 M3 and is the answer not in the manual?

IBM System x3550 M3 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Number of processors installed	2
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
RAID levels	0, 1, 10
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	-
Total storage capacity	0 GB
Maximum storage capacity	8 TB
Number of HDDs installed	0
Internal memory	24 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	6 x 4 GB
Maximum graphics card memory	16 MB
Graphics card family	Matrox
Graphics card memory type	GDDR2
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Power supply	460 W
Power supply type	AC
Power requirements	100 - 240 V
Power supply input frequency	50 - 60 Hz
Compatible operating systems	Microsoft Windows Server 2008 R2 and 2008, Red Hat Enterprise Linux, SUSE Linux Enterprise Server and VMware ESXi, Oracle Solaris 10 (model dependent)
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	8 - 80 %
Chassis type	Rack (1U)
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0
