IBM System x3650 M4 HD 12
Table 5. Maximum memory speeds (Part 2: UDIMMs and LRDIMMs)
DIMM specification UDIMM LRDIMM
Rank Dual rank Quad rank
Part number 00D5016 (8 GB) 46W0761 (32 GB)
Rated speed 1600 MHz 1866 MHz
Rated voltage 1.35 V 1.5 V
Operating voltage 1.35 V 1.5 V 1.5 B
Max. qty supported* 16 16 24
Max. DIMM capacity 8 GB 8 GB 32 GB
Max. memory capacity 128 GB 128 GB 768 GB
Max. memory
at rated speed
None 128 GB 256 GB
Maximum operating speed
1 DIMM per channel 1333 MHz 1600 MHz 1866 MHz
2 DIMMs per channel 1333 MHz 1600 MHz 1600 MHz
3 DIMMs per channel No support No support 1066 MHz
* The maximum quantity that is supported is shown for two processors installed.
The following memory protection technologies are supported:
ECC

Chipkill (for x4-based memory DIMMs)

Memory mirroring

Memory rank sparing

If memory mirroring is used, DIMMs must be installed in pairs (minimum of one pair per each CPU), and
both DIMMs in a pair must be identical in type and size.
If memory rank sparing is used, then a minimum of one quad-rank DIMM or two single-rank or dual-rank
DIMMs must be installed per populated channel (the DIMMs do not need being identical). In rank sparing
mode, one rank of a DIMM in each populated channel is reserved as spare memory. The size of a rank
varies depending on the DIMMs that are installed.

IBM System x3650 M4 HD Specifications

General

Memory Slots	24 DIMM slots
Form Factor	2U rack
Chipset	Intel C600 series
Expansion Slots	Up to six PCIe 3.0 slots
Processor	Intel Xeon E5-2600 v2 product family
Memory	Up to 768 GB
Storage	Hot-swap SAS/SATA/SSD
Storage Capacity	Up to 16 TB
RAID Support	RAID 0, 1, 10
Power Supply	Dual 750W or 900W hot-swap power supplies
Network Interface	Four integrated Gigabit Ethernet ports
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
