IBM System x3650 M4 HD 13
The following table lists the memory options that are available for x3650 M4 HD server.
Table 6. Memory options
Part
number
Feature
codes
Description Maximum
supported
Standard
models
where used
UDIMMs
00D5016 A3QC 8GB (1x8GB, 2Rx8, 1.35V) PC3L-12800 CL11 ECC DDR3
1600MHz LP UDIMM
16 (8 per
CPU)
-
RDIMMs - 1866 MHz
00D5020 A3QD 4GB (1x4GB, 1Rx4, 1.5V) PC3-14900 CL13 ECC DDR3
1866MHz LP RDIMM
24 (12 per
CPU)
-
00D5028 A3QF 4GB (1x4GB, 2Rx8, 1.5V) PC3-14900 CL13 ECC DDR3
1866MHz LP RDIMM
24 (12 per
CPU)
-
00D5032 A3QG 8GB (1x8GB, 1Rx4, 1.5V) PC3-14900 CL13 ECC DDR3
1866MHz LP RDIMM
24 (12 per
CPU)
G3x, H3x
00D5040 A3QJ 8GB (1x8GB, 2Rx8, 1.5V) PC3-14900 CL13 ECC DDR3
1866MHz LP RDIMM
24 (12 per
CPU)
83x, J3x, L3x,
M3x
00D5048 A3QL 16GB (1x16GB, 2Rx4, 1.5V) PC3-14900 CL13 ECC DDR3
1866MHz LP RDIMM
24 (12 per
CPU)
-
RDIMMs - 1600 MHz
00D5024 A3QE 4GB (1x4GB, 1Rx4, 1.35V) PC3L-12800 CL11 ECC DDR3
1600MHz LP RDIMM
24 (12 per
CPU)
-
00D5036 A3QH 8GB (1x8GB, 1Rx4, 1.35V) PC3L-12800 CL11 ECC DDR3
1600MHz LP RDIMM
24 (12 per
CPU)
B3x, C3x,
D3x, E1x,
EAx, F3x
00D5044 A3QK 8GB (1x8GB, 2Rx8, 1.35V) PC3L-12800 CL11 ECC DDR3
1600MHz LP RDIMM
24 (12 per
CPU)
-
46W0672 A3QM 16GB (1x16GB, 2Rx4, 1.35V) PC3L-12800 CL11 ECC
DDR3 1600MHz LP RDIMM
24 (12 per
CPU)
-
LRDIMMs
46W0761 A47K 32GB (1x32GB, 4Rx4, 1.5V) PC3-14900 CL13 ECC DDR3
1866MHz LP LRDIMM
24 (12 per
CPU)
-

IBM System x3650 M4 HD Specifications

General

Memory Slots	24 DIMM slots
Form Factor	2U rack
Chipset	Intel C600 series
Expansion Slots	Up to six PCIe 3.0 slots
Processor	Intel Xeon E5-2600 v2 product family
Memory	Up to 768 GB
Storage	Hot-swap SAS/SATA/SSD
Storage Capacity	Up to 16 TB
RAID Support	RAID 0, 1, 10
Power Supply	Dual 750W or 900W hot-swap power supplies
Network Interface	Four integrated Gigabit Ethernet ports
Operating System Support	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware
