Move
the
spiral
tube
until
it
reaches
at
the
cable
guide
of
the
LCD
cover
as
in
this
figure.
Make
sure
that
the
antenna
cable
is
not
pinched
by
cable
clip
(
a
).
8
a
7.
Secure
the
LCD
panel
with
the
screws.
8.
Attach
the
right
latch
to
the
LCD
cover
.
1
2
Removing
and
replacing
a
FRU
ThinkPad
T40/T40p,
T41/T41p,
T42/T42p
Series
173
178
180
