IBM THINKPAD T60 - Page 101

For models with 14.1-in. LCD:
3
3
2
4
4
4
Step Screw (quantity) Color Torque
3 M2 × 5 mm, flat-head, nylon-coated (2) Black 0.167 Nm
(1.7 kgfcm)
In step 4, strip off the tapes securing the antenna cables, and release the cables
from the cable guides of the frame.
When installing: Do not pinch the antenna cables when you attach the LCD
connector.
(continued)
Removing and replacing a FRU
ThinkPad T60 and T60p (14.1-inch and 15.0-inch) 95
