IBM THINKPAD T60 - 1060 Keyboard

1060 Keyboard
For access, remove these FRUs in order:
v “1010 Battery pack” on page 63
v “1040 Palm rest or palm rest with fingerprint reader” on page 67
1
Step Icon Screw (quantity) Color Torque
1 M2 × 14 mm, flat-head, nylon-coated
(1)
Black 0.167 Nm
(1.7 kgfcm)
Lift the keyboard a little in the direction shown by arrow 2, and then detach the
connector 3.
2
3
Removing and replacing a FRU
ThinkPad T60 and T60p (14.1-inch and 15.0-inch) 75
