IBM THINKPAD T60 - 1030 Hard Disk Drive Cover, Hard Disk Drive, and Hard Disk Drive Rubber Rails

1030 Hard disk drive cover, hard disk drive, and hard disk
drive rubber rails
For access, remove this FRU:
v “1010 Battery pack” on page 63
Attention
v Do not drop the hard disk drive or apply any physical shock to it. The
hard disk drive is sensitive to physical shock. Improper handling can cause
damage and permanent loss of data.
v Before removing the drive, have the user make a backup copy of all the
information on it if possible.
v Never remove the drive while the system is operating or is in suspend
mode.
1
Step Screw (quantity) Color Torque
1 Hard disk drive screw, nylon-coated (1) Black 0.167 Nm
(1.7 kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad T60 and T60p (14.1-inch and 15.0-inch) 65
