IBM THINKPAD T60 - 1070 Modem Daughter Card (MDC-1.5)

1070 Modem daughter card (MDC-1.5)
For access, remove these FRUs in order:
v “1010 Battery pack” on page 63
v “1040 Palm rest or palm rest with fingerprint reader” on page 67
v “1060 Keyboard” on page 75
1
1
2
Step Screw (quantity) Color Torque
1 M2 × 3 mm, small-head, nylon-coated (2) Silver 0.167 Nm
(1.7 kgfcm)
In step 2, remove the card by pulling the tab with your fingers in the direction
shown by the arrow.
(continued)
Removing and replacing a FRU
ThinkPad T60 and T60p (14.1-inch and 15.0-inch) 77
