Turn over the structure frame and proceed to step 2.
5
3
4
5
2
In step 4, remove the security hole bracket in the direction of the arrow.
Step Screw (quantity) Color Torque
3 M2 × 3.5 mm, flat-head, nylon-coated (1) Black 0.167 Nm
(1.7 kgfcm)
5 M2 × 3.5 mm, flat-head, nylon-coated (2) Black 0.167 Nm
(1.7
kgfcm)
6
7
Removing and replacing a FRU
ThinkPad T60 and T60p (14.1-inch and 15.0-inch) 105
