For 15.0-in. LCD models:
Note: Red cable is the wireless WAN antenna cable (MAIN). Wireless WAN blank
cover does not have the cable.
1
When installing: As you route the cables, make sure that they are not subjected to
any tension. Tension could cause the cables to be damaged by
the cable guides, or a wire to be broken.
2
Removing and replacing a FRU
122 MT 1951, 1952, 1953, 1954, 1955, 1956, 2007, 2008, 2009, 2613, 2623, and 2637
